CNC Cylindrical Grinder SMART 125/175

Home/Products/Turning/Flat Bed Lathe CNC/Medium Duty CNC Lathe B32

Designed for components requiring higher accuracy level. The ideal grinder combining precision, high speed and productivity for large batch and mass production in automobile, bearings and allied industries.

Salient Features :

»	Two axes CNC cylindrical grinding machine.
»	Auto profile dressing by interpolation of both axes.
»	Provision for interfacing of in-process gauge, auto flagging and auto dynamic balancing.
»	Rapid return and auto positioning of wheel slide dressing position.
»	Program test through dry run.
»	Straight feed.

Description

Specifications :

		SMART 125	SMART 175
Centre height	mm	125	175
Grinding length	mm	300/500	750
Swing over table	mm	250	350
Max. job weight with steady	kg	100/150	180
Table speed m/min	m/min	0.1-10.0	0.1-10.0
Grinding wheel size (ODxW)	mm	400x40 (50 opt.)	500x60 (70 opt.)
Peripheral / cutting speed - Std./Opt.	m/sec	33 / 45	33 / 45
Total power requirement	kW	10	12
Control system	kW	Fanuc
